After fiber laser cutting is shut down for a long time, in order to ensure the safe and reliable operation of the equipment, extend the service time, and avoid unnecessary trouble caused by irregular startup for future use, the following steps should be followed before startup:
1. Start the main power supply and voltage regulator power supply (Before starting the power supply, all lines must be checked whether there is damage or bad contact phenomenon).
2. Switch on the main power switch (NO).
3. After filling the chiller with water, start the power switch (the water level should be above the green area) and check whether the water temperature (low temperature end 25, high temperature water 28), water pressure is normal, and whether there is leakage at the water pipe joints.
4. Start the laser power switch (wait until the high and low temperature of the chiller is stable at the set value before starting).
5. Open the switch of nitrogen, oxygen and main valve to check whether the output pressure is normal and whether there is air leakage (in the case of air compressor, start the main power supply of air compressor and the cold and dry power supply).
6. Start the laser cutting software, manually operate the X/Y/Z axis motion is normal, click back to the origin, check the ceramic ring, nozzle is tight, open the BCS100 for servo calibration, floating head calibration, automatic adjustment.
7. Check whether the protective lens is contaminated, and make sure that the coaxial is in the center of the nozzle.
8. Manually blow air to confirm whether the gas pressure is normal
9. Adjust the process parameters and cutting drawings to ensure the correct processing parameters.
10. Press the frame button to ensure that the red light is within the range of the plate.
11. Start processing, the machine must be monitored by the operator when running.
